AmeriGlide - Pro Dumbwaiter

spacer
$5,499.00
On SALE!

Normally $5,499.00

Sale Ends - Apr 1, 2024
$5,499.00
No Sales Tax

The AmeriGlide Pro Dumbwaiter simple yet elegant design can fit within any modern residential buildings. Its automatic custom controls, drive lift chain and aluminum guide rail system are built to last for whatever you need moved from floor to floor.
  • With our qualified technicians, your dumbwaiter can be installed quickly and safely.
  • The AmeriGlide Pro Dumbwaiter comes with a Stainless Steel car in standard and custom made to measure models. With plenty of options, it can be manufactured to perfectly fit your home and your needs.
  • As one of North America's leaders in mobility and accessibility products, we understand your connection to your home and we understand the important role our products have in your lives.
  • The Pro Dumbwaiter is manufactured in North America, meeting ASME 17.5 & CSA B44 (Section 7) standards, and includes a 2 year warranty.
  • Call/Send Stations Included
  • In Use Car Lights Included
  • Electro-mechanical Door Interlocks Included (ASME-A17.1 and CSA B44)
Product Specifications
Max Travel - Standard12.5'
Max Travel - Optional40'
Car Size - Standard20"W x 20"D x 30"H
Car Size - Optional30"W x 30"D x 30"H
Stops - Standard2
Stops - Optional4
Weight Capacity - Standard300 Lbs
Stainless Steel Panel OptionNo
Hardwood Door OptionNo
Straight Through Car OptionYes
90° Car OptionYes

Options Available for the AmeriGlide - Pro Dumbwaiter

  • Job Reference
    • Job Name / PO   $0.00

      No Image
  • Residential / Commercial
    • Residential   $0.00

      No Image
    • Commercial   $1,750.00

      No Image
  • Car Configuration - As Viewed From Bottom Landing
    • Single Opening - Right   $0.00

      Single Opening - Right
    • Single Opening - Left   $0.00

      Single Opening - Left
    • Single Opening - Front   $0.00

      Single Opening - Front
    • Straight Through   $1,450.00

      Straight Through
    • 90 Degree - Right   $1,999.00

      90 Degree - Right
    • 90 Degree - Left   $1,999.00

      90 Degree - Left
  • Stops
    • 2 Stops   $0.00

      No Image
    • 3 Stops   $1,299.00

      No Image
    • 4 Stops   $1,999.00

      No Image
  • Car Dimensions
    • Additional Lead Time Required   $0.00

      No Image
    • 20"W x 20"D x 30"H   $0.00

      No Image
    • 24"W x 24"D x 30"H   $850.00

      No Image
    • 30"W x 30"D x 30"H   $850.00

      No Image
    • 30"W x 30"D x 36"H   $1,999.00

      No Image
    • Custom Car - Up to 30"W x 30"D x 36"H (enter dimensions below)   $3,495.00

      No Image
  • Custom Car Width, Depth & Height (Clear)
    • Inside Clear Dimensions are in Whole Inches Only   $0.00

      No Image
    • Width (min. 16" - max. 30")   $0.00

      No Image
    • Depth (min. 16" - max. 30")   $0.00

      No Image
    • Height (min. 30" - max. 36")   $0.00

      No Image
  • Options
    • 3rd Stainless Steel Shelf (2 Included)   $499.00

      No Image
    • Gate Switch on Car Gate   $640.00

      No Image
    • AC Automatic Car Light (Battery Light Included)   $450.00

      No Image
    • Mount Controller Outside Hoistway   $2,299.00

      No Image
    • Mount Motor on Top   $2,299.00

      No Image
    • Buffer Springs   $450.00

      No Image
    • 20" x 30" Fire Rated Landing Door   $1,199.00

      No Image
    • 30" x 30" Fire Rated Landing Door   $1,299.00

      No Image
    • 30" x 36" Fire Rated Landing Door   $1,295.00

      No Image
    • 20" x 30" Melamine Landing Door   $895.00

      No Image
    • 30" x 30" Melamine Landing Door   $995.00

      No Image
    • 20" x 20" Machine Access Door   $699.00

      No Image
  • Power Options
    • AC   $0.00

      No Image
    • DC   $0.00

      No Image
  • Travel Measurements
    • Bottom Floor Sill Height (typical 36")   $0.00

      No Image
    • Min Sill Height at Lowest Landing is 18" for a 30" Cab Height & 22" for a 36" Cab Height   $0.00

      No Image
    • Total Travel Bottom Floor to Top Floor (up to 50') (distance in inches)   $0.00

      No Image
    • Top Floor Sill Height (typical 36")   $0.00

      No Image
    • Overhead requirements are 90" & 96" respectively for 30" & 36" cab heights based on a 36" sill height at top landing   $0.00

      No Image
    • For each inch above 36" Top Floor Sill Height, add an additional inch to the overhead requirement.   $0.00

      No Image
    • Elevation Notes   $0.00

      No Image
  • Total Travel
    • Up to 12.5' (150")   $0.00

      No Image
    • Up to 17.1' (205") 55" Extension x 1   $1,250.00

      No Image
    • Up to 21.7' (260") 55" Extension x 2   $1,999.00

      No Image
    • Up to 26.3' (315") 55" Extension x 3   $2,495.00

      No Image
    • Up to 30.8' (370") 55" Extension x 4   $3,450.00

      No Image
    • Up to 35.4' (425") 55" Extension x 5   $4,450.00

      No Image
    • Up to 40.0' (480") 55" Extension x 6   $4,999.00

      No Image
  • Drawings
    • Drawing Revisions (2 are Standard) Call for Price for Additional   $0.00

      No Image
    • E-Mail for Approval Drawings (required to get drawings)   $0.00

      No Image
  • Fees
    • Kentucky Permit Fee   $87.50

      No Image
    • Georgia Permit & Inspection Fees   $250.00

      No Image
  • Delivery Options
    • Pickup at Terminal   $0.00

      No Image
    • Site Shipping - Customer Provided Fork Lift OR Loading Dock on Site   $0.00

      No Image
    • Site Shipping - Liftgate Delivery   $250.00

      No Image
    • Site Shipping - Flatbed & Forklift Delivery (Available in Most Areas)   $1,495.00

      No Image
  • Shipping
    • Factory Pickup   $0.00

      No Image
    • Customer Coordinated, F.O.B. Factory   $0.00

      No Image
    • AK, HI, non-US State - Call for Price   $0.00

      No Image
    • Zone 1 - ME, VT, NH, MA, RI, CT, NY, NJ, PA, DE, MD, DC, VA, NC, WV, OH, MI   $1,395.00

      No Image
    • Zone 2 - SC, GA, AL, MS, TN, AR, MO, IL, IN, KY, IA, WI, MN   $1,625.00

      No Image
    • Zone 3 - FL, LA, OK, KS, NE, SD, ND   $1,850.00

      No Image
    • Zone 4 - TX, NM AZ, UT, CO   $2,195.00

      No Image
    • Zone 5 - CA, NV, OR, ID, WY, MT, WA   $2,395.00

      No Image
